Vibgyorlighting / Product catalog p.05Solder bars / Lead-free
SnCu, SAC and pure tin options for wave soldering, solder baths and PCB electroplating.
Standard packing
500 g per bar. Approx. 300 × 20 × 15 mm. Hand-formed, so dimensions may vary. 40 bars per carton (20 kg net). Carton: 32 × 21 × 8 cm. Custom 1 kg lead-free bars available.
RoHS and SGS documentation ↗ · Ask our sales team which documents apply to your grade and batch.
Product specification
| Product / alloy (wt%) | Grade | Listed melt | Standard bar size | Application | Enquire |
|---|---|---|---|---|---|
| Lead-free solder barsSn99.3Cu0.7 | Standard alloy | 227°C | 500 g · approx. 300 × 20 × 15 mm | Wave soldering, dip soldering, hand soldering | Select ↗ |
| Lead-free solder barsSn99Ag0.3Cu0.7 | Standard alloy | 221°C | 500 g · approx. 300 × 20 × 15 mm | Wave soldering, dip soldering, hand soldering | Select ↗ |
| Lead-free solder barsSn96.5Ag3.0Cu0.5 | Standard alloy | 217°C | 500 g · approx. 300 × 20 × 15 mm | Wave soldering, dip soldering, hand soldering | Select ↗ |
| Lead-free solder barsSn99.95 (pure tin) | Standard alloy | 232°C | 500 g · approx. 300 × 20 × 15 mm | Wave soldering, dip soldering, hand soldering | Select ↗ |
Melting values are reproduced by product format from the catalog. They are not reflow settings. Confirm the selected grade and process before production.
From specification to supply
Include alloy or grade, dimensions, application and quantity in your enquiry. Confirm packaging, storage, transport and available technical documentation for the selected product.
Review a sample in your own equipment and process before a volume order.
